Power HD TR-4 Mini Waterproof Servo 2.6KG 0.10sec@7.4V

  • Model: PHDTR-4
  • Units in Stock: 361
  • UPC: 6929138004008
  • Manufactured by: PowerHD

Ask Your LHS!

Login For Price

Quantity:

Mini waterproof servo TR-4, specific for Traxxas TRX-4. Having compatibility with high voltage 6V-8.4V, at 7.4V input the servo pulls up to 2.6kg-cm of torque at a speed of down to 0.10s. A long 35cm receiver wire and mini size of 22.5 x 12.5 x 24.0 mm ensures the servo is a direct fit in Traxxas TRX-4. The servo TR-4 comes with 25T metal spline and special gaskets make it waterproof for go-everywhere capabilities.

Specifications
Torque(4.8V):1.8 kg-cm (25.0 oz/in)
Torque(6.0V):2.2 kg-cm (30.6 oz/in)
Torque(7.4V):2.6 kg-cm (36.1 oz/in)
Speed:0.15 sec (4.8V)
0.12 sec (6.0V)
0.10 sec (7.4V)
Operating Voltage:4.8 ~ 7.4 DC Volts
Spline:25T
Connector Wire Length:350mm / 13.75"
Case Colour:Blue
Weight:16.0g (0.56 oz)
Gear Type:Copper & Aluminum
Operating Temperature:-20°C ~ 60°C
Working frequency:1520 micro seconds / 50hz
Size:22.5x12.5x24.0mm (0.89x0.49x0.94")
